68P81083C20-D December 6, 2004
Test Equipment, Service Aids and Tools: Field Programming 3-3
* Available through Taunusstein Parts only.
The following table lists the tools recommended for working on the radio; these also are available
from Motorola. Note that the R-1070A workstation requires the use of a specific “heat focus head” for
each of the components on which this item is used. Each of these heat focus heads must be ordered
separately.
2705438Y01
2705816W03
2705815W03
Chassis Eliminator
Chassis Eliminator
Chassis Eliminator
For Low Power radios.
For Mid Power radios.
For High Power radios.
TKN9152A Securenet Keyload Adapter Connects radio to Securenet Keyloader
3080370E05 Securenet Extender Cable Connects the control head to the secure board.
RVN4113 Radio Service Software
MCS 2000 Series
For programming of MCS 2000 radios with SmartNet/Zone, START-
SITE and Conventional StatAlert software. (3 1/2” floppy disc,
English version)
GVN6011 (Eng)* Radio Service Software
2000 & 2100 Series Select 5
For programming of MCS 2000 radios with Conventional Select 5
software. Only compatible with VHF and UHF 1-25 Watt models. (3
1/2” floppy disc)
The use of Mini UHF Adapters will have damaging effects on
the RF Antenna Connector which might lead to radio failure.
Table 3-3. Recommended Service Tools
Part Number Description Application
0180381B45 110VAC
or
0180300E06 220VAC
MBT250 Surface-mount/throu-hole repair
station
Temperature-controlled, self-contained soldering/
desoldering repair station for installation and
removal of surface-mounted devices.
8180369E97 Flux holder/applicator Allows for the proper amount of flux to be applied
to pad grid arrays for repair.
1105139W02 30cc plastic syringe and flux paste For use with flux holder/applicator 8180369E97.
0180386A81 Miniature digital read-out soldering station
(encl. 1/64” micropoint tip)
0180386A78 Illuminated magnifying glass with lens
attachment
0180386A82 Anti-static grounding kit Used during all radio assembly and disassembly
procedures
6684253C72 Straight prober
6680384A98 Brush
1010041A86 Solder (RMA type), 63/37, 0.020" diame-
ter,1 lb. spool
Table 3-2. Service Aids
Part Number Description Application
!
a u t i o
