Motorola MCS 2000 Service Instructions

68P81083C20-D December 6, 2004
Mobile Radio Model Numbering System xxi
Specifications for VHF, 1-25 Watt Radios
All specifications are per European Telecommunication Standard (ETS) 300-086 unless otherwise
noted.
GENERAL RECEIVER TRANSMITTER
Temperature Range:
Operating: -25 to +55°C
Storage: -40 to +85°C
Power Supply:
Nominal Voltage: 13.6 V
Operating Voltage: 10.8-15.6 V
Current Drain, maximum values:
Stand-by: 0.45 A
Receive:
1.7 A with 7.5 W speaker
2.5 A with 13 W speaker
1.5 A with 4 W speaker
Transmit: 8.75 A
Off 35 mA
Number of Modes:
Model I: Standard 48, optional 150
Model II, III: Standard 160, optional 250
Channel Spacing: 12.5, 20, 25 kHz
Mode of Operation:
Simplex/Half-Duplex
Modulation: FM/PM
Antenna Impedance: 50 ¾
Frequency Stability: ±5.0 ppm
Dimensions (H/W/D):
1-25 Watt Transceiver:
44x168x180 mm / 1.73”x6.61”x7.09”
Control Head I, Dash Mt.:
44x168x30 mm / 1.73”x6.61”x1.18”
Control Head II, III, Dash Mt.:
60x190x30 mm / 2.36”x7.48”x1.18”
Control Head II, III, Remote Mt.:
60x190x71 mm / 2.36”x7.48”x2.80”
Weight:
1-25 Watt Transceivers: 1.6 kg / 3.53 lbs
Control Head I, Dash Mt.: 152 g / 0.33 lbs
Control Head II, Dash Mt.: 233 g / 0.51 lbs
Control Head III, Dash Mt.: 229 g / 0.50 lbs
Frequency Range: 136-174MHz
Maximum Frequency Separation: 38 MHz
Sensitivity:
20dB SINAD:
12.5 kHz: 0.45 uV
20/25 kHz: 0.35 uV
12dB SINAD: 0.30 uV
Adjacent Channel Selectivity:
12.5 kHz: >70 dB
20 kHz: >75 dB
25 kHz: >80 dB
Spurious / Image Rejection: >80 dB
Intermodulation: >70 dB
Conducted Spurious Emission: <2 nW
Audio Output:
12.5 kHz: 4 W (internal, 16 ¾)
20/25 kHz: 7.5/13 W (external, 8 ¾/3.2 ¾)
Audio Response:
6 dB/octave +1/-3 dB at 300-3000 Hz
Distortion:
EIA: <3%
CEPT: <5%
Frequency Range: 136-174MHz
RF Power: 1 - 25 Watts variable
Deviation, Maximum:
12.5 kHz channel spacing: ±2.5 kHz
20 kHz channel spacing: ±4.0 kHz
25 kHz channel spacing: ±5.0 kHz
Spurious & Harmonics: <0.25 uW
Audio Response:
6 dB/octave +1/-3 dB at 300-3000 Hz
Distortion:
<3% @ 60% of maximum deviation
Adjacent Channel Power (CEPT):
12.5 kHz: -60 dB
20/25 kHz: -70 dB
Specifications subject to change without notice.
