Motorola MCS 2000 Service Instructions

68P81083C20-D December 6, 2004
Mobile Radio Model Numbering System xix
Kit-To-Model Structure
The cross-reference charts below show the kit breakdown for each of the MCS 2000 models. Table
3-1 covers the VHF and UHF models and Table 3-2 covers the 800 MHz and 900 MHz models.
Table 3-1. Kit-to-Model Structure for VHF and UHF Radios
Item Description HUD4012D RF/Ctrl Bd, VHF, 1-25W HUD4015A RF/Ctrl Bd, VHF1/VHF2, 110W HUD4021A PA VHF1, 110W HUD4016A PA VHF2,110W HUE4021C RF/Ctrl Bd, UHF1, 1-10W HUE4012C1 RF/Ctrl Bd, UHF1, 10-25W HUE4011B2 RF/Ctrl Bd, UHF2, 10-25W NUE4022A RF/Ctrl Bd, UHF2, 40 W HUE4030A PA, UHF1, 110W HUE4017A RF/Ctrl Bd, UHF, 110W HCN1116A Removable Buttons HCN1117A Removable Buttons HCN1118A Removable Buttons HLN6544A Housing, LP (Š25W), VHF/UHF HHN4041A Housing, MP (25-40W) HHN4039A Housing, HP (110W) HLN6354A Trstr Hw kit V/U 25W HLN6357A Trstr Hw kit VHF/UHF 40W HLN6353A Trstr Hw kit U2 25W
Model Description
•••
M01KHL9PW4_N, VHF1, 25W, Mod. I
• • •
M01KHM9PW5_N, VHF1, 25W, Mod. II
•••
M01KHN9PW5_N, VHF1, 25W, Mod. III
• • • •
M01JLM9PW6_N, VHF1, 110W, Mod. II
•• • •
M01JLN9PW6_N, VHF1, 110W, Mod. III
• • • •
M01KLM9PW6_N, VHF2, 110W, Mod. II
•• • •
M01KLN9PW6_N, VHF2, 110W, Mod. III
• • •
M01RFL9PW4_N, UHF1, 10W, Mod. I
•••
M01RFM9PW5_N, UHF1, 10W, Mod. II
• • •
M01RFN9PW5_N, UHF1, 10W, Mod. III
•• •
M01RHL9PW4_N, UHF1, 10-25W, Mod. I
• • •
M01RHM9PW5_N, UHF1, 10-25W, Mod. II
•••
M01RHN9PW5_N, UHF1, 10-25W, Mod. III
• • • •
M01RLM9PW6_N, UHF1, 110W, Mod. II
••••
M01RLN9PW6_N, UHF1, 110W, Mod. III
• •
M01SHL9PW4_N, UHF2, 25W, Mod. I
••
M01SHM9PW5_N, UHF2, 25W, Mod. II
• •
M01SHN9PW5_N, UHF2, 25W, Mod. III
•• •
M01SKM9PW6_N, UHF2, 40W, Mod. II
• • •
M01SKN9PW6_N, UHF2, 40W, Mod. III

Motorola MCS 2000 Specifications

General

Brand	Motorola
Model	MCS 2000
Category	Radio
Language	English
