MTS 793 Controller Hardware
FlexTest IIm Controller Connections
196
Cable Part Numbers
Refer to the following table for cable part numbers used to connect test
hardware to the Model 497.01 Analog Chassis rear-panel connectors.
D
ESCRIPTION CABLE PART NUMBER
Load cell, 661.xx w/MS connector 046-440-6XX
Load cell, 661.xx w/PT connector 046-440-2XX
Strain w/PT connector 050-120-0XX
LV D T 046-440-3XX
ADT–120º 048-341-1XX
Remote E-stop/X-head Interlock-load frame 054-145-4XX
Servovalve, 252.xx single 046-440-1XX
Servovalve, 252.xx dual 046-440-4XX (in-phase); 046-440-5XX (out-of-phase)
Jumper plug 2nd servovalve eliminator 039-705-901
Servovalve, 256.xx w/valve 046-440-1XX
Servovalve, 256.xx w/valve LVDT 046-440-8XX
ΔP stability 047-927-6XX
ΔP stability–dual cells 048-049-6XX
System ground–console MTD FlexTest 005-402-3XX
HSM on-off
039-705-3XX (24 V DC); 039-719-1XX (115 V AC)
1
HSM high-low 292.xx/298.xx
039-705-5XX (24 V DC); 039-719-2XX (115 V AC)
1
HSM on-off 292.xx/298.xx
039-708-1XX (24 V DC)
1
413.07 Hydraulic interface to 298.12 prop HSM 042-664-5XX (24 V DC)
497.05 Control Panel to 413.07
042-075-701 (24 V DC)
1
HPS (HSM power not included)
039-708-7XX (24 V DC); 039-708-8XX (115 V AC)
1
Y adapter at HPS 005-407-801 (24 V DC); 005-401-801 (115 V AC)
1. For CE configurations, there are CE versions of these cables. Refer to the System Cable Package
Selection-FlexTest drawing (PN 047-922-501) for these cable numbers.
