Chapter 4 NETWORK SETUP MENU
110
ASCII Data Port
This option sets the port number for ASCII print jobs. The data port
number needs to match your host system setting.
• 9100 (default)
• 1023 - 65535
IPDS Data Port
This option allows you to set the port number for IPDS print jobs
only if the IPDS option is installed.
The range is 0 - 5000, and the factory default is 5001.
Keep Alive Timer
This is the time that the Keep Alive Timer will run. With the Keep
Alive Timer on, the tcp connection will stay connected even after
the print job has terminated.
• 3 Minutes (default)
• 2 - 10 Minutes
Ethernet Speed
This menu option only appears if a 10/100Base-T network interface
card (NIC) is installed. The Ethernet Speed menu allows
compatibility with different systems and networks. The factory
default is Auto Select.
• Auto Select. (default) This setting tells the 10/100Base-T NIC
to perform an auto detection scheme and configure itself to be
10 Half Duplex, 10 Full Duplex, 100 Half Duplex, or 100 Full
Duplex.
• 10 Half Duplex. Tells the 10/100Base-T NIC to communicate
at 10 Megabits per second using half duplex.
• 10 Full Duplex. Tells the 10/100Base-T NIC to communicate at
10 Megabits per second using full duplex.
