Chapter 4 IPDS Emulation
258
Barcode Speed
This parameter chooses the vertical print quality of barcode labels.
• High (default). Barcodes are printed with less vertical dots,
increasing printing speed, but decreasing print quality.
• Select By Host. The application decides the quality of the
labels.
• Low. Barcodes are printed with more vertical dots, decreasing
printing speed, but increasing print quality.
Barcode Size
This parameter will emulate the barcode sizes of the selected
printer model.
• 4234 (default). IBM 4234
• 67XX. Decision Data 67XX
• 64XX. IBM 6400 series
• 4224. IBM 4224
Early Print Comp (Complete)
This parameter chooses when to send a Print Comp to the
controller.
• Off (default). Print Comp is sent if page is printed completely.
• On. Print Comp is sent immediately. The next page will be
created. This improves the print performance when starting the
next page.
NOTE: When Early Print Comp is enabled and an error occurs,
you may lose data.
