Chapter 4 Main Menu
70
Brief descriptions follow for the first-level configuration menu
options:
• QUICK SETUP — These options allow quick access to the
most frequently changed or inputted parameters during the
installation of the printer.
• CONFIG. CONTROL — These options allow you to save, print,
load, delete, name, and reset entire sets of configuration
parameters.
• HOST INTERFACE — These options allow you to select either
the Serial RS-232, Serial RS-422, Centronics
®
parallel,
Dataproducts
®
parallel and Long Lines, Ethernet
â„¢
, IEEE
®
1284 parallel, Auto Switching, Coax or Twinax interface for the
printer. This menu also allows you to configure several
parameters for each interface.
• NETWORK SETUP — This option allows you to select from
Ethernet Address options and Ethernet Parameters options.
• ACTIVE (IGP) EMUL — This menu allows you to select the
PGL or VGL emulation from the menu if IGP is installed.
• EMULATION — This menu allows you to configure the options
which are available for the current operating (active) emulation.
For example, if LinePrinter+ is the active emulation, then the
LinePrinter+ emulation options can be configured using this
menu.
• PRINTER CONTROL — These options allow you to select
parameters common to a general user, such as display
language and Barcode quality.
• ADVANCED USER — These options allow you to select
several advanced operating parameters for the printer, such as
the speed at which paper will advance when slewing.
• DIAGNOSTICS — These options include the diagnostic tests,
system memory, and statistics of the printer.
