Omron E5*C Series User Manual

5 Advanced Operations
5 - 44
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This section provides the procedures to set PID-related parameters manually.
* You do not need to set these parameters manually if you set them automatically with AT (autotuning).
Setting Example
In this example, the PID 1 Proportional Band parameter (for PID set 1) is set to 20.0.
5-13-3 Setting PID Set Parameters
Operating Procedure
z Setting the PID 1 Proportional Band (PID Setting Level)
1 Move to the PID Setting Level. The Display PID Selection
parameter is displayed.
PID Setting Level
2 Press the U or D Key to select 1 (PID set 1).
The default is the currently selected PID set.
3 Press the M Key to display the PID 1 Proportional Band param-
eter.
PID Setting Level
4 Press the U or D Key to set 20.0 .
The default is 8.0.
Continue by pressing the M Key to display the other parameters
for PID set 1. Change the settings of the parameters as necessary.
1
d.pid
Display PID
Selection
1
d.pid
8.0
1.p
PID 1
Proportional
Band
20.0
1.p
