Omron E5*C Series User Manual

5 - 11
5 Advanced Operations
E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-4 Using Event Inputs
5
5-4-1 Event Input Settings
5-4 Using Event Inputs
• The number of event inputs that is supported depends on the model of the Digital Controller.
E5CC-T: Up to 4 event inputs
E5EC-T/E5AC-T: Up to 6 event inputs
• Event inputs can be used for changing between run and reset status, changing between automatic
and manual operation, holding, advancing, inverting direct/reverse operation, changing the SP mode,
executing/canceling 100% AT, executing/canceling 40% AT, executing/canceling 100% AT for all PID
sets, executing/canceling 40% AT for all PID sets, enabling/disabling setting changes,
enabling/disabling communications write, canceling the alarm latch, enabling/disabling wait
operation, and changing the program number.
The following table shows the functions that can be assigned when an Event Input Assignment 1 or 6
parameter is displayed.
*1 The event input must be turned OFF first before this function can be activated again. This function is enabled
only during program operation.
*2 These functions are enabled only in reset status.
*3 This function is enabled only when the Reset Operation parameter is set to stop control.
*4 This function can be set for heating/cooling control or for floating control for Position-proportional Models, but
the setting will be disabled.
*5 This function can be set only for a Controller that supports communications. Also, when a work bit is selected
as the event input data, Communications Write Enable/Disable cannot be assigned.
5-4-1 Event Input Settings
5-4-2 Using Event Inputs
Setting Function
none None
rr-1 Run (OFF)/Reset (ON)
rr-2 Run (ON)/Reset (OFF)
manu Auto/Manual
rst Reset
run Run
hld1 Hold/Clear Hold
hld2 Hold
adv
Advance
*1
prg0
Program Number Switch 0
*2
prg1
Program Number Switch 1
*2
prg2
Program Number Switch 2
*2
drs Invert Direct/Reverse Operation
spm
Program SP Mode/Fixed SP Mode
*3
at-2 100% AT Execute/Cancel
at-1
40% AT Execute/Cancel
*4
ata2 All PID 100% AT Execute/Cancel
ata1
All PID 40% AT Execute/Cancel
*4
wtpt Setting Change Enable/Disable
cmwt
Communications Writing Enable/Disable
*5
lat Alarm Latch Cancel
wait Wait Enable/Disable
