Omron E5*C Series User Manual

4 Basic Operation
4 - 14
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This example shows how to create the following program with rate of rise programming.
In this example of rate of rise programming, the program starts with a ramp. Program operation is
started from the PV. To start operation from a specific SP, set the Segment Format parameter for seg-
ment 0 to a step.
z Related Parameters
4-2-3 Initial Setup Example for Rate of Rise Programming
Programming Example for Rate of Rise Programming
Parameter Settings Setting level
Input Type
5: K thermocouple (default) Initial Setting Level
PID ON/OFF
2-PID control (default) Initial Setting Level
Alarm type
2: Upper-limit (default) Initial Setting Level
Program Time Unit
Hours and minutes (default) Initial Setting Level
Step Time/Rate of Rise
Programming
Rate of rise programming Initial Setting Level
Time Unit of Ramp Rate
Minutes (default) Initial Setting Level
Reset Operation
Stop control (default) Initial Setting Level
Startup Operation
Continue (default) Initial Setting Level
Operation End
Operation
Reset status (default) Initial Setting Level
SP Mode
PSP: Program SP (default) Adjustment Level
Alarm Value
30°C Program Setting Level
Program Number
0 (default) Program Setting Level
Number of Segments
Used
4 Program Setting Level
PID Set No.
1 (default) Program Setting Level
Segment Number
012Program Setting Level
Segment Format
Ramp
(default)
Soak Ramp
(default)
Program Setting Level
Segment SP
100 --- 60 Program Setting Level
Segment Slope
4 --- 2 Program Setting Level
Segment Time
--- 0.40 --- Program Setting Level
Time (h.min)
20 min.
100°C
60°C
Segment 0
(ramp)
Segment 2
(ramp)
Segment 1 (soak)
PV at
startup
= 20°C
Operation started in Program SP Mode.
20 min.40 min.
SP
4 Rate of fall
2 Rate of fall
1 min. Time Unit of Ramp Rate
1 min. Time Unit of Ramp Rate
