A - 19
A Appendices
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-6 Parameter Operation Lists
A
A-6-2 Program Setting Level
A-6-2 Program Setting Level
Parameter Characters Setting (monitor) value Display Default Unit
Display Program
Selection
d.prg 0 to 7 Number of
program
currently
used for
control.
None
Number of Segments
Used
s-no 1 to 32 8 None
Display Segment
Selection
d.seg END or 0 to Number of segments used − 1ENDNone
Segment n Format styp n = 0 to 31
Ramp, Soak, or Step
ramp, soak,
step
Ramp None
Segment n SP sp n = 0 to 31
SP lower limit to SP upper limit
0EU
Segment n Slope pr n = 0 to 31
0 to 9,999
0 EU/Time Unit
of Ramp Rate
Segment n Time time n = 0 to 31
0.00 to 99.59
0.00 Program
Time Unit
PID Set No. pid 0 to 8 (0: Auto selection) 1 None
Alarm Value 1 al-1
Alarms Other Than an MV Alarm
larm
−1999 to 9999
0EU
MV Alarms
−199.9 to 999.9
0.0 %
Alarm Upper Limit 1 al1h −1999
to
9999 0 EU
Alarm Lower Limit 1 al1l −1999
to
9999 0 EU
Alarm Value 2 al-2
Alarms Other Than an MV Alarm
la
−1999
to
9999
0EU
MV Alarms
−199.9 to 999.9
0.0 %
Alarm Upper Limit 2 al2h −1999
to
9999 0 EU
Alarm Lower Limit 2 al2l −1999
to
9999 0 EU
Alarm Value 3 al-3
Alarms Other Than an MV Alarm
larm
−1999 to 9999
0EU
MV Alarms
−199.9 to 999.9
0.0 %
Alarm Upper Limit 3 al3h −1999
to
9999 0 EU
Alarm Lower Limit 3 al3l −1999
to
9999 0 EU
Alarm Value 4 al-4
Alarms Other Than an MV Alarm
larm
−1999 to 9999
0EU
MV Alarms
−199.9 to 999.9
0.0 %
Alarm Upper Limit 4 al4h
−1999
to
9999
0EU
Alarm Lower Limit 4 al4l −1999
to
9999 0 EU
Program Repetitions rpt 0
to
9999 0 Repetitions
Program Link
Destination
link END or 0 to 7 END None
Time Signal 1 Set
Segment
ts1s 0
to
31 0 None
Time Signal 1 ON Time on1 0.00
to
99.59 0.00 Program
Time Unit
Time Signal 1 OFF
Time
of1 0.00
to
99.59 0.00 Program
Time Unit
Time Signal 2 Set
Segment
ts2s 0
to
31 0 None
Time Signal 2 ON Time on2 0.00
to
99.59 0.00 Program
Time Unit
Time Signal 2 OFF
Time
of2 0.00
to
99.59 0.00 Program
Time Unit
To Next Page
