3 Part Names and Basic Procedures
3 - 4
E5@C-T Digital Temperature Controllers User’s Manual (H185)
3-3 Part Names, Part Functions, and
Setting Levels
3-3-1 Part Names and Functions
E5CC-T
E5EC-T
Operation indicators
Temperature unit
Front panel
PV or specified monitor/setting item
SP or specified monitor/setting value
No. 1 display
No. 2 display
Top-panel Setup Tool port
Press S Key to change the digit (default setting).
Top View of E5CC-T
Press the U D Keys to set
the parameter.
Press U Key for at least 1
second when SP and PV are
displayed in Program SP
Mode to go to Display
Segment Selection parameter
in Program Setting Level.
Press O Key for at least 3
seconds to go to Initial
Setting Level.
Press the M Key to change to another
parameter.
Press
O
Key once to go to
Program Setting Level.
Press
M
and
D
Keys simultaneously for
at least 1 second to change between run
and reset status.
Operation indicators
Temperature unit
Front-panel Setup Tool port
No. 1 display
No. 2 display
No. 3 display
PV or specified monitor/setting item
Top View of E5EC-T
Press the U D Keys to
set the parameter.
Top-panel
Setup
Tool port
Front panel
Press S Key to move the
digit (default setting).
SP or specified monitor/setting value
Program No., segment No.,
remaining segment time, or
MV (valve opening).
Press U Key for at least 1
second when SP and PV are
displayed in Program SP Mode to
go to Display Segment Selection
parameter in Program Setting
Level.
Press
M and D Keys simultaneously for
at least 1 second to change between run
and reset status.
Press
O Key once to go to Program Setting Level.
Press O Key for at least 3 seconds to go to Initial
Setting Level.
Press the M Key to change to another
parameter.
