Omron E5*C Series User Manual

3 - 9
3 Part Names and Basic Procedures
E5@C-T Digital Temperature Controllers User’s Manual (H185)
3-3 Part Names, Part Functions, and Setting Levels
3
3-3-3 Setting Levels
On the E5@C-T, the parameters are classified into levels according to their applications. These levels
are called setting levels. The setting levels consist of some basic setting levels and other setting levels.
The following figure gives an overall image of the setting levels. The setting levels consist of the basic
setting levels (shaded below) and the other setting levels (not shaded).
The Initial Setting Level, Communications Setting Level, Advanced Function Setting Level, and Calibra-
tion Level can be used only when control is stopped. If you change to any of these levels, control will
stop.
3-3-3 Setting Levels
Moving between Setting Levels
