6 Parameters
6 - 80
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-10 Advanced Function Setting Level
The Advanced Function Setting Level is used for
optimizing Controller performance. To move to this
level, input the password ("−169") from the Initial Set-
ting Level.
To be able to enter the password, the Initial Set-
ting/Communications Protect parameter in the Pro-
tect Level must be set to 0.
Moving to Advanced Function Setting
Level
1 Move from the Operation Level to the Protect
Level.
2 Display the Initial Setting/Communications
Protect parameter.
3 Change the set value to 0.
4 Move from the Protect Level to the
Operation Level to the Initial Setting Level.
5 Display the Move to Advanced Function
Setting Level parameter.
6 Change the set value to −169.
7 The Advanced Function Setting Level is
displayed.
init (INIT) will be displayed.
• The parameters in this level can be used when the
Initial Setting/Communications Protect parameter
is set to 0.
• To switch between setting levels, press the O Key.
• To change set values, press the U and D Keys.
1
icpt
Initial Setting/
Communications Protect
Set 0. Default: 1
0
amov
Move to Advanced
Function Setting Level
Set −169. Default: 0
25
100
Password input
set value −169
Control in progress
Control stopped
Operation
Level
Initial Setting Level
Control stops.
Adjustment
Level
Advanced Function
Setting Level
Press the
O Key for
at least 1 s.
Press the
O Key for less than 1 s.
Press the
O Key for
at least 1 s
to flash
the
display.
Press the O Key for
at least 3 s.
Press the
O Key for less than 1 s.
Press the
O Key for
at least 1 s.
Power ON
Communi-
cations
Setting Level
Program
Setting Level
PID Setting
Level
