A Appendices
A - 20
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-6-3 Adjustment Level
Parameters Characters Setting (monitor) value Display Default Unit
Adjustment Level
Display
l.adj
AT Execute/Cancel at OFF, AT Cancel
AT-2: 100%AT Execute
AT-1: 40%AT Execute
*1
ATA1: All PID 40% AT Execute
*1
ATA2: All PID 100% AT Execute
off, at-2,
at-1, ata1,
ata2
OFF None
Communications
Writing
cmwt OFF, ON off, on OFF None
SP Mode spmd PSP: Program SP
FSP: Fixed SP
psp, fsp PSP None
Fixed SP fsp SP lower limit to SP upper limit 0 EU
Heater Current 1 Value
Monitor
ct1 0.0 to 55.0 A
Heater Burnout
Detection 1
hb1 0.0 to 50.0 0.0 A
Heater Current 2 Value
Monitor
ct2 0.0 to 55.0 A
Heater Burnout
Detection 2
hb2 0.0 to 50.0 0.0 A
Leakage Current 1
Value Monitor
lcr1 0.0 to 55.0 A
HS Alarm 1 hs1 0.0 to 50.0 50.0 A
Leakage Current 2
Value Monitor
lcr2 0.0 to 55.0 A
HS Alarm 2
hs2 0.0 to 50.0 50.0 A
PV Input Shift ins Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −1,999 to 9,999 0 EU
PV Slope Coefficient inrt 0.001 to 9.999 1.000 None
Wait Band wt-b Temperature input: OFF, or 0.1 to 999.9 off or 0.1 to
999.9
OFF °C or °F
Analog input: OFF, or 0.01 to 99.99 off or 0.01
to 99.99
OFF %FS
Standby Time stb 0.00 to 99.59 (hours.minutes) 0.00 Standby
Time Unit
0.00 to 99.23 (days.hours)
Program SP Shift
Value
psps −1,999 to 9,999 0 EU
Proportional Band p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time i Standard,
heating/cooling, or close
position-proportional
control:
Integral/Derivative Time
Unit of 1 s: 0 to 9,999
233 Seconds
Integral/Derivative Time
Unit of 0.1 s: 0.0 to 999.9
233.0 Seconds
Floating
position-proportional
control:
Integral/Derivative Time
Unit of 1 s: 1 to 9,999
233 Seconds
Integral/Derivative Time
Unit of 0.1 s: 0.1 to 999.9
233.0 Seconds
Derivative Time d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Proportional Band
(Cooling)
c-p Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time (Cooling) c-i Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
233
233.0
Seconds
Derivative Time
(Cooling)
c-d Integral/Derivative Time Unit of 1 s: 0 to 9,999
Integral/Derivative Time Unit of 0.1 s: 0.0 to 999.9
40
40.0
Seconds
Dead Band c-db Temperature input: −199.9 to 999.9 0.0 °C or °F
Analog input: −19.99 to 99.99 0.00 %FS
Manual Reset Value of-r 0.0 to 100.0 50.0 %
