This section provides example setting procedures for step time programming and rate of rise program-
ming for the following program pattern.
1
On the Basic Tab Page, set the Step Time/Ramp Rate Programming (Rate of Rise
Programming) Box to Step Time.
The default setting is Step Time.
2
On the Program Tab Page, set the Program 0 Number of Segments Box to 4.
The default setting is 0.
3
On the Pattern Tab Page, set the Segment Set Point and Segment Time Boxes to the
values given below.
5-23-4 Program Setting Procedures
Example Procedure for Step Time Programming
Segment No. 0 1 2 3
Segment Set Point 60°C100°C100°C60°C
Segment Time 0 min. 20 min. 40 min. 20 min.
Segment 1
Segment 0
Time
signal 1
Time
signal 2
20 min.
60.0°C
100.0°C
40 min. 20 min.
Segment 2
Segment 3
SP
Time
(h.min)
