Omron E5*C Series User Manual

5 Advanced Operations
5 - 96
E5@C-T Digital Temperature Controllers User’s Manual (H185)
z Pattern Tab Page
Use this tab page to set each of the segments in a program.
z Time Signal Tab Page
Use this tab page to set the time signals for a program.
Parameter name Description Controller Setting Level Page
Segment Set Point
This parameter sets the SP for the specified
segment number.
Program Setting Level 6-18
Segment Time
This parameter sets the segment time for the
specified segment number.
For rate of rise programming, this parameter
sets the time for a soak segment.
Program Setting Level 6-19
Parameter name Description Controller Setting Level Page
Time Signal 1 and 2 Set
Segment
These parameters set the segment
numbers that will use time signals.
Program Setting Level 6-22
Time Signal 1 and 2 ON
Time
These parameters set the ON times
for the time signals.
Program Setting Level 6-23
Time Signal 1 and 2 OFF
Time
These parameters set the OFF times
for the time signals.
Program Setting Level 6-23
