4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-2 Initial Setup Examples through Starting Program Operation
4
4-2-2 Initial Setup Example for Step Time Programming
This example shows how to create the following program with step time programming.
In this example of step time programming, the program starts with a ramp. The segment time is 0, so
you set only the segment SP.
z Related Parameters
4-2-2 Initial Setup Example for Step Time Programming
Programming Example for Step Time Programming
Parameter Parameter Setting level
Input Type
5: K thermocouple (default) Initial Setting Level
PID ON/OFF
2-PID control (default) Initial Setting Level
Alarm type
2: Upper-limit (default) Initial Setting Level
Program Time Unit
Hours and minutes (default) Initial Setting Level
Step Time/Rate of Rise
Programming
Step time programming (default) Initial Setting Level
Reset Operation
Stop control Initial Setting Level
Startup Operation
Continue (default) Initial Setting Level
Operation End
Operation
Reset status (default) Initial Setting Level
SP Mode
PSP: Program SP (default) Adjustment Level
Program Number
0 (default) Program Setting Level
Number of Segments
Used
4 Program Setting Level
PID Set No.
1 (default) Program Setting Level
Alarm Value
30°C Program Setting Level
Segment Number
0123Program Setting Level
Segment SP
50 100 100 50 Program Setting Level
Segment Time
0.00 0.20 0.40 0.20 Program Setting Level
Time (h.min)
20 min.
100°C
Segment 0
Segment 1 Segment 2 Segment 3
50°C
Operation started in Program SP Mode.
20 min.40 min.
SP
