1 Introduction
E5@C-T Digital Temperature Controllers User’s Manual (H185)
1-1 Appearance, Features, and
Functions of the E5@C-T
1
1-1-3 Main Functions
You can use a key operation to freely jump to another segment and execute it.
From the initial display in Operation Level, you can change to the display to edit segment data with one
key.
When you use more than one PID set, you can set all of the PID constants at the same time to reduce
adjustment work.
You can press the M (Mode) Key and the D Key simultaneously for 1 second or longer to change the
program between run status and reset status.
You can use key operations to hide parameters that do not need to be displayed to prevent incorrectly
setting parameters and to simplify the parameter configuration.
For details on particular functions and how to use them, refer to Section 3 Part Names and Basic Proce-
dures and following sections.
z Input Sensor Types
You can connect the following sensors and signals to the universal input.
z Control Outputs
• A control output can be a relay output, voltage output (for driving SSR), or linear current output,
depending on the model.
z Program Controls
Program Patterns
• Programs: 8 patterns max., Segments: 32 max. per program
• Program initial set point: Segment 0 set point, present value (PV), or fixed SP
• Program start time: Standby operation (delay) can be set.
• Repeating and linking programs are also possible.
Controlling the Program
• Run (program operation started)/Reset (program operation stopped)
• Advancing the segment
Controlling the Program
Editing the Program
AT for All PID Sets
Addition of Operation to Change Program between Run and Reset
Parameter Mask Settings
1-1-3 Main Functions
Thermocouple (temperature input): K, J, T, E, L, U, N, R, S, B, W, PLII
Resistance thermometer (temperature input): Pt100, JPt100
Infrared Temperature Sensor (temperature input): ES1B
10 to 70°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Current input (analog input): 4 to 20 mA DC, 0 to 20 mA DC
Voltage input (analog input): 1 to 5 VDC, 0 to 5 V DC, 0 to 10 V DC
