Omron E5*C Series User Manual

A - 21
A Appendices
E5@C-T Digital Temperature Controllers User’s Manual (H185)
A-6 Parameter Operation Lists
A
A-6-3 Adjustment Level
*1 This setting is not displayed for heating and cooling control or for floating position-proportional control.
Hysteresis (Heating) hys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Hysteresis (Cooling) chys Temperature input: 0.1 to 999.9 1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
MV at Reset mv-r Standard: −5.0 to 105.0
Heating/cooling: −105.0 to 105.0
0.0 %
Floating position-proportional control or the Direct
Setting of Position-proportional MV parameter set to
OFF: CLOS, HOLD, or OPEN
clos, hold,
open
HOLD None
Close position-proportional control with the Direct
Setting of Position-proportional MV parameter set to
ON: −5.0 to 105.0
0.0 %
MV at PV Error mv-e Same as for MV at Reset.
MV Upper Limit ol-h Standard control: MV lower limit + 0.1 to 105.0
Heating/cooling control: 0.0 to 105.0
100.0 %
Close position-proportional control: MV lower limit +
0.1 to 105.0
MV Lower Limit ol-l Standard control: −5.0 to MV upper limit − 0.1 0.0 %
Heating/cooling control: −105.0 to 0.0 −100.0
Close position-proportional control: −5.0 to MV
upper limit −0.1
0.0
MV Change Rate Limit orl 0.0 to 100.0
(0.0: MV Change Rate Limit Disabled)
0.0 %/s
Position Proportional
Dead Band
db Close position-proportional control: 0.1 to 10.0 4.0 %
Floating position-proportional control: 0.1 to 10.0 2.0
Open/Close Hysteresis oc-h 0.1 to 20.0 0.8 %
Extraction of Square
Root Low-cut Point
sqrp 0.0 to 100.0 0.0 %
Work Bit * ON Delay
w1
to 8on
0 to 9999 0 Seconds
Work Bit * OFF Delay
w1
to 8of
0 to 9999 0 Seconds
Communications
Monitor
plcm 0 to 9999 ms
Parameters Characters Setting (monitor) value Display Default Unit
