3 Part Names and Basic Procedures
E5@C-T Digital Temperature Controllers User’s Manual (H185)
3-3 Part Names, Part Functions, and Setting Levels
3
3-3-1 Part Names and Functions
E5AC-T
Displays
Name Description
No. 1 display Displays the process value or a monitor/setting item.
No. 2 display Displays the set point or the value of a monitor/setting item.
No. 3 Display
(E5EC-T/E5AC-T
only)
Displays the program number, segment number, remaining segment time, or MV (valve
opening). (The value that is displayed is set in the PV/SP Display Selection parameter in
the Advanced Function Setting Level.)
Temperature unit Displays the temperature unit (C or F).
Top View of E5AC-T
Operation indicators
PV or specified monitor/setting item
SP or specified monitor/setting value
Front Panel
Top-panel
Setup
Tool port
No. 1 display
No. 2 display
No. 3 display
Program No., segment No.,
remaining segment time, or MV
(valve opening).
Temperature unit
Front-panel Setup Tool port
Press the O Key for at least
3 seconds to go to the Initial
Setting Level.
Press the S Key to change the digit (default
setting).
Press the M Key to change to another
parameter.
Press U Key for at least 1 second
when SP and PV are displayed in
Program SP Mode to go to Display
Segment Selection parameter in
Program Setting Level.
Press O Key once to go to
Program Setting Level.
Press M and D Keys simultaneously for at
least 1 second to change between run and
reset status.
Press the U or D Key
to set the parameter.
To Next Page
