4 - 15
4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-2 Initial Setup Examples through Starting Program Operation
4
4-2-3 Initial Setup Example for Rate of Rise Programming
Operating Flow for Rate of Rise Programming
Item Operating flow Settings Page
Turn ON the power supply and then press the O
Key for at least three seconds to move to the Initial
Setting Level.
4-3
1 Make
the
initial
settings
other
than
program
-related
settings.
Set the parameter to a K thermocouple
(default).
4-18
Set the parameter to PID control (default). 4-21
Set the parameter to an upper-limit alarm (default). 4-56
2 Make
the ini-
tial pro-
gram-rel
ated set-
tings.
Set the parameter to hours and minutes (default). 4-33
Set the parameter to rate of rise programming.
(default).
4-34
Set the parameter to minutes (default). 4-35
Set the parameter to stop control (default). 4-35
Set the parameter to continue operation (default). 4-36
Set the parameter to reset status (default). 4-38
Set the parameter to the program SP (default). 4-38
Power ON
Set the Input Type parameter.
Set the Alarm Type parameter.
Initial Setting Level
Set the PID ON/OFF parameter.
Set the Program Time Unit parameter.
Initial Setting Level
Set the Startup Operation parameter.
Set the Operation End Operation parameter.
Set the Reset Operation parameter.
Set the Step Time/Rate of Rise Programming parameter.
Set the Time Unit of Ramp Rate parameter.
Set the SP Mode parameter.
Adjustment Level
