6 - 51
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-7 Monitor/Setting Item Level
6
pfd1 to 5
Monitor/Setting Item Display 1 to 5
The PF Setting parameter must be set to PFDP, and
the Monitor/Setting Item 1 to 5 parameters must not
be set to OFF.
• When the PF Key is set to display monitor/setting items, pressing the PF Key will display
in order the contents of the Monitor/Setting Item 1 to 5 parameters. The contents of these
parameters are shown in the following table. For the setting (monitor) ranges, refer to the
applicable parameters.
*1 With the E5CC-T, only the PV and SP can be displayed. The SP can be selected only in Fixed
SP Mode.
*2 The setting for the currently selected PID set number is displayed.
*3 The setting for the currently selected program number is displayed.
Set value Setting
Remarks
Monitor/Setting Display
0 Disabled --- ---
1 PV/SP/Program No. Monitor and Segment No.
Monitor
Can be set. (SP)
*1
---
2 PV/SP/MV (Heating) (Valve Opening for
Position-proportional Models)
Can be set. (SP)
*1
---
3 PV/SP/MV (Cooling)
Can be set. (SP)
*1
---
4 PV/SP/Remaining Segment Time
Can be set. (SP)
*1
---
5 Program No. Can be set. prg
6 Segment No. Monitor Cannot be set. seg
7 Remaining Standby Time Monitor Cannot be set. stbm
8 Elapsed Program Time Monitor Cannot be set. prgt
9 Remaining Program Time Monitor Cannot be set. prgr
10 Elapsed Segment Time Monitor Cannot be set. segt
11 Remaining Segment Time Monitor Cannot be set. segr
12 Program Execution Repetitions Monitor Cannot be set. rptm
13 Proportional band Can be set.
p
*2
14 Integral time Can be set.
i
*2
15 Derivative time Can be set.
d
*2
16 Proportional Band (Cooling) Can be set.
c-p
*2
17 Integral Time (Cooling) Can be set.
c-i
*2
18 Derivative Time (Cooling) Can be set.
c-d
*2
19
Alarm value 1
*3
Can be set. al-1
20
Alarm value upper limit 1
*3
Can be set. al1h
21
Alarm value lower limit 1
*3
Can be set. al1l
22
Alarm value 2
*3
Can be set. al-2
23
Alarm value upper limit 2
*3
Can be set. al2h
24
Alarm value lower limit 2
*3
Can be set. al2l
25
Alarm value 3
*3
Can be set. al-3
26
Alarm value upper limit 3
*3
Can be set. al3h
27
Alarm value lower limit 3
*3
Can be set. al3l
28
Alarm value 4
*3
Can be set. al-4
29
Alarm value upper limit 4
*3
Can be set. al4h
30
Alarm value lower limit 4
*3
Can be set. al4l
