Omron E5*C Series User Manual

6 - 53
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-8 Manual Control Level
6
PV/MV (Manual MV)
• The manual control level display appears as shown below.
* When the Manual MV Limit Enable parameter is set to ON, the setting range will be the MV lower
limit to the MV upper limit.
z Related Parameters
Standard or Heating/Cooling (Initial Setting Level): Page 6-64
Function
50.0
25
PV/Manual MV
Monitor range Unit
Process value Temperature: According to indication range for each sensor.
Analog: Scaling lower limit −5% FS to Scaling upper limit +5% FS
(Refer to A-7 Sensor Input Setting Range, Indication Range, Con-
trol Range.)
EU
Set point SP lower limit to SP upper limit EU
Setting range Unit
MV (Manual MV) Standard control
Position-proportional control
−5.0 to 105.0* %
Heating/cooling control −105.0 to 105.0*
See
See
