Omron E5*C Series User Manual

6 Parameters
6 - 112
E5@C-T Digital Temperature Controllers User’s Manual (H185)
Refer to the E5 @ C-T Digital Controllers Communications Manual (Cat. No. H186) for details.
Protocol Setting Parameter = Host Link (FINS) or MC Protocol (Type 4)
Protocol Setting Parameter = Component Communications
• Each parameter is enabled when the power is reset.
• Match the communications specifications of the E5@C-T and the host computer. If
multiple devices are connected, ensure that the communications specifications for all
devices in the system (except the Communications unit number) are the same.
z Related Parameter
Communications Writing (Adjustment Level): Page 6-28
Parameter
Parameter
display
Display Settings Default
Highest Communications
Unit No.
maxu 0 to 99 0 to 99 0
Area areaAREA 0 to 25 0 to 25 0
First Address Upper Word adrh 0 to 99 0 to 99 0
First Address Lower Word adrl 0 to 9999 0 to 9999 0
Receive Data Wait Time rwat 100 to 9999 100 to 9999 ms 1000
Communications Node
Number
unit 0 to 99 0 to 99 0
Upload Settings 1 to 23 up1 to 23 0 to 179 0 to 179
Download Settings 1 to 43 dn1 to 43 30 to 179 30 to 179
Copy copy off, all, 1 to 31 OFF
Parameter
Parameter
display
Display Settings Default
Highest Communications
Unit No.
maxu 0 to 99 0 to 99 0
Receive Data Wait Time rwat 100 to 9999 100 to 9999 ms 1000
Copy copy off, all, 1 to 31 OFF
Function
Setting
* The Communications Writing parameter will be automatically turned ON if the Protocol Setting
parameter is set to component communications, Host Link (FINS) communications, or the MC
Protocol (Type 4).
Item Display Set values Settings Default
Protocol setting psel cwf/
mod
cmp
fins
mcp4
CompoWay/F
Modbus
Component communications
Host Link (FINS)
MC Protocol (Type 4)
cwf
Communications
Unit No.
u-no 0 to 99 0 to 99 1
Communications
baud rate
bps 9.6/19.2/38.4/57.6
(Kbps)
9.6/19.2/38. 4/57.6 (kbps) 9.6
Communications
data length
len 7 or 8 bits 7 or 8 bits 7
Stop bits sbit 1 or 2 bits 1 or 2 bits 2
Communications
parity
prty none/eVen/odd None, Even, Odd eVen
Send data wait
time
sdwt 0 to 99 0 to 99 (ms) 20
