8 - 3

8 Pulse Output Units

NX-series Position Interface Units User’s Manual (W524)

8-1 Interpreting Model Numbers

The model number of the Pulse Output Unit tells you the Unit type, number of axes, I/O specifications,

and other information.

NX-PG0

NX Series

Unit Type

Number of Channels

Pulse Output Specification and I/O Polarity

Additional Functions

2: Supports synchronous refreshing

1: Open collector output, NPN

2: Open collector output, PNP

1: 1 channel

PG0: Pulse Output Unit
