A - 29
Appendices
NX-series Position Interface Units User’s Manual (W524)
A-2 Object Lists
A
A-2-2 Incremental Encoder Input Units
This section describes the product information objects, I/O allocation objects, and message communi-
cations objects for Incremental Encoder Input Units.
These objects are related to product information.
A-2-2 Incremental Encoder Input Units
Unit Information Objects
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type Access
I/O
allo-
cat-
ion
Data
attri-
bute
1000 --- NX Bus Identity infor-
mation
--- --- --- --- --- --- ---
00 Number of Entries 7 7 --- USINT RO No ---
02 Model
*1
*1. This returns the model of the Unit in ASCII. If all 12 bytes are not required, the remaining bytes are filled with spaces ($20).
--- --- ARRAY
[0..11] OF
BYTE
RO No ---
06 Unit Version
*2
*2. Bits 24 to 31: Integer part of the unit version
Bits 16 to 23: Decimal part of the unit version
Bits 0 to 15: Reserved
--- --- UDINT RO No ---
1001 --- Production Info --- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO No ---
01 Lot Number
*3
*3. Bits 24 to 31: Day of month of manufacture
Bits 16 to 23: Month of manufacture
Bits 8 to 15: Year of manufacture
Bits 0 to 7: Reserved
00000000 to
FFFFFFFF hex
--- UDINT RO No ---
