Omron NX-EC0112 User Manual

2 - 3
2 Specifications and Application Procedures
NX-series Position Interface Units User’s Manual (W524)
2-2 Operating Procedures
2
2-2-1 Procedures When Using the Motion Control Function Module
2-2 Operating Procedures
The operating procedures for the Position Interface Units depend on the system configuration.
For example, even when you use an NJ/NX-series Controller, the operating procedures depend on
whether the MC Function Module is also used.
This section describes the basic operating procedures that are required to use the Units.
This section describes the basic operating procedures that are required to use the MC Function Module
in an NJ/NX-series Controller.
Additional Information
Refer to the NJ/NX-series CPU Unit Motion Control User's Manual (Cat. No. W507) for the
main operating methods.
However, the NJ/NX-series CPU Unit Motion Control User's Manual (Cat. No. W507) is written
based on the assumption that a G5-series Servo Drive or Motor is used. Some of the material
does not apply if you use a Pulse Output Unit.
Refer to 8-9-2 Precautions When Using the Pulse Output Unit on page 8-42 for information on
the differences between when a G5-series Servo Drive or Motor is used and when a Pulse Out-
put Unit is used.
2-2-1 Procedures When Using the Motion Control Function Module
