3 Click the button located on the right side of Safety network number (NX bus).
The Safety Network Number Settings Dialog Box is displayed.
When you click the Auto Option, the Safety Network Number (SNN) is automatically generated
from the current time information of the computer on which the Sysmac Studio is running.
When you click the Manual Option, enter a unique number that is not used in any other sys-
tem.
4 Click the OK Button.
The Safety Network Number (SNN) is determined, and UNID is updated.
Additional Information
You can also enter the Safety Network Number (SNN) directly in the Safety Network Number
Settings T
ab Page.
Originator Connection Settings
To use the Safety CPU Unit as an originator device for CIP Safety, the CIP Safety communications
need to be set. Use the following procedure to set the CIP Safety communications.
l
Adding Target Devices
Use the following procedure to add a target device to open a CIP Safety connection.
1 In the Multiview Explorer, select the target Safety CPU Unit in the Controller Selection Box.
2 Select Configurations and Setup – Communications – Safety –
EtherNet/IP Safety
Connection Settings and double-click Connection Settings (Originator).
Connection Settings (Originator) Tab Page is displayed.
A list of target devices that can be set for the connection is shown in the Toolbox.
5 System Configuration and Setup
5 - 14
NX-series Safety Control Unit User's Manual (Z930)
To Next Page
