3 Change the initial values of the variables.
6-8-5
Feedback Settings
You can set input status that is linked to changes in output status, such as feedback inputs for safety
relays.
Simulation must be stopped to make the feedback settings.
Use the following setting procedure.
1 Select Simulation – Feedback Settings.
The Feedback Setting Dialog Box is displayed.
Item Description
Supported variable
types
Input
Set a global variable
*1
that is the destination of the feedback.
You cannot set a variable that is already set as a feedback destination.
BOOL, SAFEBOOL
*2
Output
Set the global variable
*1
that is the source of the feedback. BOOL, SAFEBOOL
*2
Invert
This check box is used to invert the input value.
If you select this check box, the input value is inverted.
---
*1. With Sysmac Studio version 1.11, you can use device variables and exposed variables only.
*2. With Sysmac Studio version 1.11, set variables with the same variable type for both the source and
destination.
With Sysmac Studio version 1.12 and later, you can set dif
ferent variable types for the source and
destination.
2 Press the Insert Key in the feedback setting table, or right-click in the feedback setting table
and select Create New from the menu.
Cells are added for new settings.
You can set up to 128 sets of feedback settings.
6 Programming
6 - 83
NX-series Safety Control Unit User's Manual (Z930)
6-8 Offline Debugging
6
6-8-5 Feedback Settings
