10-1
Safety Unit Restore
The safety unit restore is a function designed to transfer safety programs and settings to Safety CPU
Unit via an SD Memory Card. This function is available for a combination of an NX102 CPU Unit with
unit version 1.31 or later, or an NX-SL5£££ Safety CPU Unit with unit version 1.3 or later, and Sys-
mac Studio version 1.24 or higher.
You can use the Safety Unit Restore in the following instances.
Item Application
Program and setting changes When you change the safety program and settings for equipment that is
currently in operation
Hardware replacement When you replace the hardware for the Safety CPU Unit
Manufacture of equipment When you want to manufacture the same equipment and need to transfer
the data from the existing equipment to new equipment in its initial state.
Safety Unit Restore is executed combining the following functions.
Function Description
Generate Safety Unit Restore
File function
This function allows to generate the Safety Unit Restore File using the Sysmac
Studio.
Safety Unit Restore function This function allows to transfer the Safety Unit Restore File data stored in an
SD Memory Card to a Safety CPU Unit
.
Note that the Safety Unit Restore function restores only the target data in NX-SL5£££ Units. To re-
store the entire system, you need to execute this function together with the SD Memory Card backup
function.
Precautions for Correct Use
• To execute the Safety Unit Restore, you need to execute the restore function for the NX102
CPU Unit as well. In addition, you need to generate a safety backup file and a backup file of
the NX102 CPU Unit from a same project or from a same project of a same physical unit
where a project was transferred from. If the settings for the safety backup file and that for the
backup file of the NX102 CPU Unit are not consistent, the safety control unit does not operate
normally.
•
Before executing the Safety Unit Restore, make sure to confirm the safety of the transfer des-
tination.
• Before executing the Safety Unit Restore, verify that the operation target is correct.
• Before executing the Safety Unit Restore, verify that the signature displayed on the seven-
segment indicator of the Safety CPU Unit is correct.
• To prevent accessing a wrong Safety Unit Restore File, make sure to control the file access
and configuration properly.
• After executing the Safety Unit Restore, verify that the Unit is configured correctly and the
Unit behaves as intended.
• To prevent executing the Safety Unit Restore by unauthorized person, make sure to keep un-
der access control to SD Memory Cards and Safety Unit Restore Files.
10-1-1
Generate Safety Unit Restore File Function
This function uses the Sysmac Studio to generate a Safety Unit Restore File from a project that in-
cludes safety application data.
10 Safety Unit Restore
10 - 2
NX-series Safety Control Unit User's Manual (Z930)
