An execution confirmation dialog box is displayed.
3 Click the Yes Button.
•
When There Is No Safety CPU Unit in the Slave Terminal Configuration
The settings of all the Units that are connected to the EtherCAT Coupler Unit are transferred
to the Sysmac Studio. This completes the upload procedure.
• When There Is a Safety CPU Unit in the Slave Terminal Configuration
A confirmation dialog box for connection to a safety device is displayed.
Go to the next step and continue the procedure.
Note You do not need to enter anything in the Instance identification Box.
4 Click the OK Button.
A password confirmation dialog box is displayed.
5 Enter the password, and click the OK Button.
The settings of all the Units that are connected to the Communications Coupler Unit are trans-
ferred to the Sysmac Studio.
Precautions for Correct Use
If you use an EtherCAT Coupler Unit, upload the data from the Safety CPU Unit only after you
have added all of the Safety I/O Units
to the EtherCAT Slave Terminal Tab Page.
If you use the following procedure to upload data and then reset the warning, you cannot moni-
tor the project.
If you upload the data from the Safety CPU Unit when not all of the Safety I/O Units are regis-
tered, a warning is displayed.
You can reset the warning by uploading data from all of the Safety I/O Units.
