Event name Safety Process Data Communications Not Estab-
lished Error
Event code 35200000 hex
Meaning Safety process data communications was not established with one or more safety slaves.
Source Depends on where the Sysmac
Studio is connected and the sys-
tem configuration.
Source details NX Unit Detection tim-
ing
In DEBUG
mode (ST
OP-
PED), DEBUG
mode (RUN),
or RUN mode
Error attrib-
utes
Level Minor fault Recovery Automatic re-
covery when
cause of error
is removed
Log category System
Effects
User program Continues. Operation The Unit continues to operate, but the safe states
are used for the I/O data of safety connection
where the error was detected.
System-de-
fined varia-
bles
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
The communications settings for
safety process data are not cor-
rect, the safety slave is not in the
correct status, etc.
Refer to the error for the safety
slave and correct the problem.
Refer to the errors for the safety
slaves and implement counter-
measures.
The safety slave for safety proc-
ess data communications is not
connected.
Make sure the safety slave is
connected correctly
.
Make sure that all of the safety
slaves to communicate with are
connected before you change
the Safety CPU Unit to DEBUG
mode (STOPPED), DEBUG
mode (RUN), or RUN mode.
The safety slave set in the NX
Unit Mounting Setting for safety
process data communications is
disabled.
Set the disabled safety slaves in
the NX Unit Mounting Setting so
that they do not participate in
safety process data communica-
tions and then transfer the data
to the Safety CPU Unit.
Set the disabled safety slaves in
the NX Unit Mounting Setting so
that they do not participate in
safety process data communica-
tions.
Attached in-
formation
None
Precautions/
Remarks
The relevant Units will maintain the safe states for I/O data with safety connections after an error is de-
tected. However
, when the cause of the error is removed, safety process data communications will re-
cover automatically
.
12 Troubleshooting
12 - 33
NX-series Safety Control Unit User's Manual (Z930)
12-3 Checking for Errors with the Sysmac Studio
12
12-3-4 Error Descriptions
