6 System Configuration and Setup
6 - 8
NX-series Safety Control Unit User’s Manual (Z930)
Set or view the settings for the Safety CPU Unit and Safety I/O Units (hereinafter, “Safety Control
Units”) as necessary.
You can change the device names of registered Safety Control Units, and enable or disable individual
Units as NX Units.
6-3-2 Setting and Viewing the Safety Control Unit Settings
Item Editing Description
Data
range
Default
Device name Possible. This is the name of the Safety Control Unit.
The device name is automatically assigned
when you register the Safety CPU Unit or
Safety I/O Unit. You can change the device
name if necessary.
Device names must be unique within the same
safety control configuration. If you specify the
same name for more than one Unit, an error
will occur.
Text
string
N* (where * is a
serial number
from 1)
Model name Not possible. This is the model number of the Safety Control
Unit.
--- ---
Product name Not possible. This is the product name. --- ---
Unit version Not possible. This is the unit version of the Safety Control
Unit.
--- ---
NX Unit
number
Not possible. This number represents the logical position of
the Safety Control Unit as an NX Unit. Num-
bers are automatically assigned from the left-
most mounting position.
--- ---
NX Unit
mounting
setting
Possible. This setting enables or disables I/O refreshing
for the Safety Control Unit.
Refer to the NX-series EtherCAT Coupler Unit
User’s Manual (Cat. No. W519) for details on
this function.
Enabled
or
Disabled
Enabled
Serial number Not possible. This is the serial number of the Safety Control
Unit. You can get the serial number to set the
serial number of the actual EtherCAT Coupler
Unit.
--- 00000000 hex
Power
consumption
[W]
Not possible. This is the power consumption of the Safety
Control Unit from the NX bus. This setting
applies to Units other than an Additional NX
Unit Power Supply Unit.
--- Depends on the
model of the
Unit.
Unit width
[mm]
Not possible. This is the width of the Safety Control Unit. --- Depends on the
model of the
Unit.
I/O allocation
settings
Not possible. These are the I/O allocation settings of the
Safety Control Unit.
--- ---
Unit operation
settings
Not possible. There are no settings that you can edit for the
Safety Control Units.
--- ---
