A - 13
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-2 NX Objects
A
A-2-5 NX-SOD400 Safety Output Unit
This object gives the product information.
A-2-5 NX-SOD400 Safety Output Unit
Unit Information Object
Index
(hex)
Sub-
index
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O allo-
cation
Data
attri-
bute
1000 --- NX Bus Identity --- --- --- --- --- --- ---
00 Number of Entries 7 7 --- USINT RO Not pos-
sible.
---
02 Model NX-SOD400 --- --- ARRAY
[0..11] OF
BYTE
RO Not pos-
sible.
---
03 Device Type 00000A03
hex
--- --- UDINT RO Not pos-
sible.
---
04 Product Code 00A30400
hex
--- --- UDINT RO Not pos-
sible.
---
05 Vendor Code 1 --- --- UDINT RO Not pos-
sible.
---
06 Unit Version
*1
*1. Bits 24 to 31: Integer part of the Unit version.
Bits 16 to 23: Fractional part of the Unit version.
Bits 0 to 15: Reserved
Example for version 1.0: 0100 hex
--- --- UDINT RO Not pos-
sible.
---
07 Serial Number
*2
*2. The unique serial number of the product is given.
Bits 0 to 31: Serial number
00000000 to
FFFFFFFF hex
--- UDINT RO Not pos-
sible.
---
1001 --- Production Info --- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not pos-
sible.
---
01 Lot Number
*3
*3. The date of manufacture is given for the lot number.
Bits 24 to 31: Day of manufacture
Bits 16 to 23: Month of manufacture
Bits 8 to 15: Year of manufacture
Bits 0 to 7: Reserved
00000000 to
FFFFFFFF hex
--- UDINT RO Not pos-
sible.
---
02 Hardware Version
*4
*4. The hardware version is given in order in the lowest elements of the array. Unused elements are padded with spaces.
--- --- ARRAY
[0..19]
OF BYTE
RO Not pos-
sible.
---
03 Software Version
*5
*5. The software version is given in order in the lowest elements of the array. Unused elements are padded with spaces.
--- --- ARRAY
[0..19]
OF BYTE
RO Not pos-
sible.
---
