A - 47
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-3 Application Examples
A
A-3-9 Safety Mats and Safety Light Curtains
Safety light curtain monitors apertural area of safeguarded space and safety mat monitors inside of
safeguarded space.
If the light in safety light curtain S3 is interrupted or safety mat S4 detects a person or object, motor M
will stop.
A-3-9 Safety Mats and Safety Light Curtains
Application Overview
Safety category/PL Safety device Stop category Reset
Equivalent to 3/PLd
(Safety Mat)
• Emergency stop pushbutton
• Safety light curtain
• Safety mat
0 Manual
