Omron NX-SID800 User Manual

9 - 17
9 Troubleshooting
NX-series Safety Control Unit User’s Manual (Z930)
9-3 Checking for Errors with the Sysmac Studio
9
9-3-4 Error Descriptions
This section describes the information that is given for individual errors.
The items that are used to describe individual errors (events) are described in the following copy of an
error table.
9-3-4 Error Descriptions
Controller Error Descriptions
Name Gives the name of the error. Event code Gives the code of the error.
Meaning Gives a short description of the error.
Source Gives the source of the error. Source details Gives details on
the source of the
error.
Detection timing Tells when the
error is detected.
Error attributes Level Tells the level of
influence on stan-
dard control.
*1
*1. This is the level of influence on standard control, and not the level of influence on safety control. One of the following:
Major fault: Major fault level
Partial fault: Partial fault level
Minor fault: Minor fault level
Observation
Information
Recovery Gives the recov-
ery method.
*2
*2. One of the following:
Automatic recovery: Normal status is restored automatically when the cause of the error is removed.
Error reset: Normal status is restored when the error is reset after the cause of the error is removed.
Cycle the power supply: Normal status is restored when the power supply to the Controller is turned OFF and then back ON after the
cause of the error is removed.
Controller reset: Normal status is restored when the Controller is reset after the cause of the error is removed.
Depends on cause: The recovery method depends on the cause of the error.
Log category Tells which log
the error is saved
in.
*3
*3. One of the following:
System: System event log
Access: Access event log
Effects User program Tells what will
happen to execu-
tion of the user
program in the
NJ/NX-series
CPU Unit.
*4
*4. This status is for the execution of the user program in the NJ/NX-series CPU Unit, and not for the execution of the safety program in the
Safety CPU Unit. One of the following:
Continues: Execution of the user program in the NJ/NX-series CPU Unit will continue.
Stops: Execution of the user program in the NJ/NX-series CPU Unit stops.
Starts: Execution of the user program in the NJ/NX-series CPU Unit starts.
Operation Provides specific information on the operation that results
from the error.
Indicators Gives the status of the indicators on the Safety Control Unit, which show status other than the event level.
System-defined
variables
Variable Data type Name
Lists the variable names, data types, and names for system-defined variables that provide direct error notification, that
are directly affected by the error, or that contain settings that cause the error.
Cause and
correction
Assumed cause Correction Prevention
Lists the possible causes, corrections, and preventive measures for the error.
Attached
information
This is the attached information that is displayed by the Sysmac Studio.
Precau-
tions/Remarks
Provides precautions, restrictions, and supplemental information.
