Appendix
A - 86
NX-series Safety Control Unit User’s Manual (Z930)
A-14 Differences in Checking Operation
between the Simulator and Safety
CPU Unit
This section describes the differences in the program debugging functions that you can perform on the
Sysmac Studio between online debugging on a Safety CPU Unit and offline debugging with the Simula-
tor.
Debugging function Safety CPU Unit Simulator Reference
Monitoring Supported. Supported. 8-6-3 Monitoring Variables
in the FBD Editor on page
8-31
8-6-4 Monitoring Variables
in a Watch Tab Page on
page 8-31
Monitoring in a Watch Tab Page Supported. Supported. 8-6-5 Controlling BOOL
Variables, Changing Pres-
ent Values, and Using
Forced Refreshing on
page 8-33
Controlling BOOL variables Supported. Supported.
Forced refreshing inputs
Supported.
*1
*1. You can use forced refreshing for up to 19 variables at the same time.
Supported.
*2
*2. You can use forced refreshing for up to 256 variables at the same time.
Changing present values of data Supported. Supported.
Monitoring Controller status Supported. Supported. 8-12 Monitoring Control-
ler Status on page 8-56
Clear All Memory operation Supported. Not supported. 8-13-2 Clear All Memory
Operation on page 8-58
Changing the operating mode Supported. Not supported. 8-3 Operating Modes of
the Safety CPU Unit on
page 8-11
Troubleshooting Supported. Not supported. Section 9 Troubleshooting
Monitoring error information Supported. Not supported.
Displaying error logs Supported. Not supported.
To Next Page
