ZFX-C User’s Manual
Top
Bottom
• Attach the connector caps to connectors that are not in use to prevent dust or dirt from getting inside the connectors
and to prevent the Controller from static electricity.
Name Function
(1) Monitor connector This connector is for connecting to the LCD monitor (option) via a monitor
cable.
(2) Camera connector This connector is for connecting to a camera.
Name Function
(1) Ethernet port This port is for connecting to a personal computer via a 100Base-TX/10Base-T
cable.
(2) RS-232C/422 connector This connector is for connecting to a PLC via an RS-232C or an RS-422 cable.
p.14
(3) Console connector
This port is for connecting to the Console.
p.14
(4) Power connector
This connector is for connecting to the DC power supply.
p.28
(5)Parallel port This port is for connecting to devices such as a PLC using the parallel cable.
p.14
, p.156
Important
