PIAGGIO 500 cc - Replacing the Countershaft Bearings; Half Crankcase Flywheel Side

8 - 7
8
05_259
05_260
05_261
- Remove the oil pump complete with gear by unloosing
the 2 fixing screws through the slots situated on the
gear itself.
- Remove the gasket.
Replacing the countershaft bearings
- Check the bearings out for anomalous noise or play.
Replace if necessary.
Half crankcase flywheel side
- Remove the snap ring situated on the inner side.
Driving shaft crankcase
05_262
- Overturn the half crankcase.
- Remove the bearing from the half crankcase flywheel
side by means of the specific tool and a hammer.
Specific tool:
Punch handle 020376Y
Adapter 37x40 mm 020358Y
17 mm guide 020439Y
