3 - 15
3
Automatic transmission
05_053
Fixed driving half pulley assembly
- Fit the spacer
- Fit the fixed driving half pulley making sure it is in
contact with the spacer and with the sliding bush of
the mobile driving pulley
05_054
- Fit the plain washer and the cup washer as shown in
the figure.
05_055
- Insert the nut in its previous position (nut side in
contact with the cup washer).
05_056
