PIAGGIO 500 cc User Manual

2 - 3
2
NECESSARY TOOLS
TOOL NAME PART NO.
STEERING SEAT FITTING TOOL, to be fitted with parts 9 - Lower 001330Y
bearing adaptor, 10 - Upper bearing adaptor
Bell Ø 80 mm 001467Y002
20 mm pliers 001467Y006
Bell Ø 63 mm 001467Y007
18 mm pliers 001467Y008
Bell Ø 45 mm 001467Y017
Bell Ø 60 mm 001467Y031
15 mm pliers 001467Y034
Hub bearing extraction bell 001467Y035
Steering tube ring spanner 020055Y
Oil pressure gauge 020193Y
Valve seal rings assembly tool 020306Y
37x40 mm adaptor 020358Y
42x47 mm adaptor 020359Y
52x55 mm adaptor 020360Y
20 mm guide (Driven pulley bearings) 020363Y
25 mm guide (Driven pulley bearings) 020364Y
Ø 28x30 mm adaptor 020375Y
Adapter sleeve 020376Y
Bushing (valve removing tool) 020382Y012
15 mm guide 020412Y
Valve oil seal extractor 020431Y
Oil pressure gauge unio 020434Y
17 mm guide (countershaft bearings) 020439Y
Driven half pulley spring compressor 020444Y
46-55 mm spanner 020444Y009
Ø 24 mm adaptor 020456Y
Steering tube lower bearing extractor 020458Y
Drift for fitting bearing on steering tube 020459Y
Injection tester kit 020460Y
Flywheel extractor 020467Y
Piston fitting band 020468Y
Injection tester reprogramming kit 020469Y
Piston pin retainer fitting tool 020470Y
Countershaft timing peg 020471Y
Flywheel retaining tool 020472Y
Clutch bell housing retaining tool 020473Y
Drive pulley stop spanner 020474Y
Piston position comparator support 020475Y
Pillar kit 020476Y
Ø 37 mm adaptor 020477Y
Driven pulley needle roller drift 020478Y
Countershaft stop spanner 020479Y
Fuel pressure measuring kit 020480Y
Control unit interface wiring harness 020481Y
30 mm guide 020483Y
Piston stop fork 020512Y
Compass wrench (valve lifter bell stop) 020565Y
Exhaust gas analyser 494929
Specific Tooling
