PIAGGIO 500 cc - Flywheel Cover Components

5 - 2
FLYWHEEL COVER
LUBRICATE WITH OIL
APPLY PRODUCT
LUBRICATE WITH GREASE
CLEAN WITH CARE
ALWAYS REPLACE
WARNING: HANDLE WITH CARE
REFERENCE A B C D E F G H I L M N O P Q
QUANTITY 614116311221
TORQUE N·m 3-4 11-13 4-5 24-30 3-4 8-10 1.5-2.5 12-16 1.5-2 3-4 3.5-4.5
B
D
E
M
H
I
G
L
F
C
