PIAGGIO 500 cc - Flywheel Cover Disassembly; Water Pump Cover Disassembly

5 - 4
Water pump cover disassembly
- Unloose the 6 fixing screws and remove the water
pump cover and relevant O ring.
N.B.: If necessary, disassemble the pump cover com-
plete with thermostat and sleeves.
05_086
05_085
Flywheel cover disassembly
- Drain the engine oil by removing the drain plug.
- Collect the oil in a suitable container.
- Remove the prefilter.
- Remove the oil filter by means of a suitable wrench.
05_087
05_088
Flywheel cover
