PIAGGIO 500 cc - Thermal Unit and Timing System Components

7 - 2
THERMAL UNIT AND TIMING SYSTEM
LUBRICATE WITH OIL
APPLY PRODUCT
LUBRICATE WITH GREASE
CLEAN WITH CARE
ALWAYS REPLACE
WARNING: HANDLE WITH CARE
REFERENCE A B C D E F G H I L M N O P Q
QUANTITY 312144441123311
TORQUE N·m 4-6 30-35 11-13 5-6 38-42 44-46 11-13 6-8 10-14 7-8,5 3-4 11-13 11-13 3-4 10-12
O
P
N
I
D
C
G
E
M
B
L
H
F
A
Q
