12 - 3
12
Starting
Controls and diagnostics guide
The starting motor is marketed as complete.
Before deciding to replace it, it is necessary to proceed with the following checks:
Battery
Check repose tension (several hours).
Tension > 12,5 V.
Check the electrolyte density of each element.
Bé = 30 - 32
Specific weight: 1.25 - 1.26
Recharge and if necessary replace the battery
NO
YES
Check correct connection of the negative terminals
(battery negative and starting motor
negative) between themselves and the chassis.
Reset the connections.
NO
YES
Connect the diagnosis tester di 020460Y
(see Chapter 9-FUEL INJECTION).
Connect the induction pliers of an amperometer to
the positive feed cable of the starting motor.
Remove the 10A fuse N° 2
(see Chapter 9-FUEL INJECTION).
Set to "ON" with the switch on "RUN"
and side stand raised.
Select the "PARAMETERS" function, page 1-3.
