4.40
Cleanfire Fuel Injection
Version Identification
1. Start the Digital Wrench® software.
2. Locate the version ID
on the title screen.
3. The version ID number should match the Digital
Wre
nch® update name.
Special Tests Menu
The SPECIAL TESTS (Tool Box Icon) in Digital Wrench®
gives the service technician the following options:
• Vehicle History Informat
ion
• Output State Control
• TPS Set Procedure
• Service Report
• ECU Replacement
• Security Functions (2012-2013 Only)
• Engine Controller Reprogramming
• Vehicle Information
• Feature Configuration/Registration
NOTE: Special Tests menu selections will populate
a
ccording to vehicle selected.
Vehicle History Information
Selecting the Vehicle History Information option displays
the following information:
• Throttle Position (TPS) history
• Engine RPM history
• Engine run time hours
• Engine overheat occurrences
• Engine overheat misfire protection mode
occurrences
• Engine run time in limp home modes
Service Report
Selecting Service Report from the SPECIAL TESTS
MENU generates a report of all of the current ECU input/
output values, model/calibration/software information,
and diagnostic trouble codes.
Technicians can add the VIN or customers’ name to the
“custome
r name”’ field and then save the service report as
a .txt file on their laptop/PC.
Clicking on “View Current” will refresh the report
infor
mation. Selecting “View Saved” will access any saved
service report .txt files saved on the laptop/PC.
