10.34
Battery and Electrical Systems
DC-CFI Chassis (Red/White) Power Circuits
REGULATED
DC VOLTAGE
CH / ENG GROUND
DC VOLTAGE
FROM CHASSIS RELAY
RED/WHT
RED
BRN -- DIRECT
DC--CFIECU34 PINCNACONNECTOR
INSTRUMENT CLUSTER
POWER
DC POWER
TEST PLUG
ACCESSORY POWER
PLUG
RD/WH
BN/WH
BROWN
BROWN
RD/YE
2 AMP FUSE
RD/WH
BN/WH
2
28
RD/WH
RD/WH
1
3
ORANGE
OR/BK
11
BRAKE SWITCH
