2010 Progressive 120 Rail Fastener Locations
Components/Fasteners:
• A - Rail Tip
• B - Limiter Strap Shaft
• C - Rail Bumper
• D - H Bracket/Bogie Wheel Shaft
• E - Bogie Wheel Asm. (Mount to outside of rail).
• F - Front Torque Arm Shaft
• G - Bogie Wheel Asm. (Mount to inside of rail).
• H - Rail Brace Shaft
• I - Rear Pivot Shaft
• J - Rail Brace Shaft
• K - Rear Idler Adjuster Block
A
B
C
D
E
F
G
H
K
J
I
LEFT RAIL SHOWN
