Pyronix 256 User Manual

PCX SMS AND PCX 256 SYSTEM MANUAL
RINS871-3 Page: 77
Type Active Restore
0059 Engineer Access
When entering Engineer Mode When leaving Engineer Mode
0060 Initialise Digi
At power up Live for 45 seconds only
0063 Test ATE/GSM*
Test signalling through
PSTN and GSM. Activates
when a test call is
sent.(used for specific
GSMs)
When test completed
0064 Test ATS
Test signalling through
PSTN and GSM. Activates
when a test call is sent.
When test completed
0066 ATE not used
Makes the ATE pin 5V.
A repeating block of output types should be noted:
0202 Hold Up A
As 0002 for Partition A / Arm Level A events only
0203 Intruder A
As 0003 for Partition A / Arm Level A events only
0204 Final Arm A
As 0004 for Partition A / Arm Level A events only
0207 Tamper A
As 0007 for Partition A / Arm Level A events only
0208 Duress A
As 0008 for Partition A / Arm Level A events only
0209 HU Device A
As 0009 for Partition A / Arm Level A events only
0213 Secure Intruder A
As 0013 for Partition A / Arm Level A events only
0214 Bell A
As 0014 for Partition A / Arm Level A events only
0216 Strobe A
As 0016 for Partition A / Arm Level A events only
0217 Omit At Rearm A
As 0017 for Partition A / Arm Level A events only
0218 Unconfirmed A
As 0018 for Partition A / Arm Level A events only
0219 Can Arm A
As 0019 for Partition A / Arm Level A events only
0220 Exit Starts A
As 0020 for Partition A / Arm Level A events only
Then this pattern repeats for each other partition, so that:
0221-0240 Partition / Arm Level B 0361-0380 Partition / Arm Level 4*
0241-0260 Partition / Arm Level C 0381-0400 Partition / Arm Level 5*
0261-0280 Partition / Arm Level D 0401-0420 Partition / Arm Level 6*
0281-0300 Partition / Arm Level 0* 0421-0440 Partition / Arm Level 7*
0301-0320 Partition / Arm Level 1* 0441-0460 Partition / Arm Level 8*
0321-0340 Partition / Arm Level 2* 0461-0480 Partition / Arm Level 9*
0341-0360 Partition / Arm Level 3*
1xxx Follow input xxx
When input is activated When input clears
i.e. add 1000 to the input number to select output required
Partition Sounder At output 2 of the RIX2 (fixed as loudspeaker)
*NOT AVAILABLE ON PCX 26/SMS
For the defaults please see page: 78
